| Video |
| Imaging Device |
1/2.8″ CMOS |
| Resolution |
2592×1944, 2560×1440, 1920×1080, 1280×960, 1280×720, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps(@5MP Max. 5fps) |
| Min. Illumination |
Color: 0.07Lux (F1.6, 1/30sec)
BW: 0.007Lux (F1.6, 1/30sec, 30IRE), 0Lux(IR LED on) |
| Video Out |
USB: Micro USB Type B, 1280×720 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
3.2~10.2mm(3.2x) motorized varifocal |
| Max. Aperture Ratio |
F1.6(Wide)~F3.1(Tele) |
| Angular Field of View |
H: 95°(Wide)~29°(Tele)
V: 69°(Wide)~21°(Tele)
D: 126°(Wide)~36°(Tele) |
| Min. Object Distance |
1.2m (3.93ft) |
| Focus Control |
Simple focus |
| Lens Type |
DC auto iris(IR corrected) |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
0°~350° / -35°~70°/ 0°~355° |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅤ, WiseNRⅡ(Based on AI engine) |
| Motion Detection |
8ea, 8point Polygonal zones |
| Privacy Masking |
32ea, 4point quadrangle zones |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
| Video Rotation |
Flip, Mirror, Hallway view(90°/270°) |
| Analytics |
Classified object type: Person/Vehicle
Attributes: Vehicle(Type:car/bus/truck/motorcycle/bicycle)
Support DetectionShot
Analytics events based on AI engine
– Motion detection*, Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit)
Analytics events
– Defocus detection, Tampering, Virtual area(Appear/Disappear)* Some of the video analytics only works with people and vehicle detection |
| Alarm I/O |
Input 1ea / Output 1ea
* Alarm I/O is supported through an optional cable(SPP-C7400) |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm events |
When alarm trigger occurred
– File upload(image) : e-mail/FTP
– Notification : e-mail
– Recording : SD/SDHC/SDXC or NAS recording at event triggers
– Alarm output
– Handover(PTZ preset, Send message by HTTP/HTTPS/TCP)
– Audio clip playback |
| Audio In |
Selectable(mic in/line in)
* Audio In is supported through an optional cable(SPP-C7400) |
| Audio Out |
Line out, Max.output level: 0.5Vrms
* Audio Out is supported through an optional cable(SPP-C7400) |
| IR Viewable Length |
30m(98.42ft) |
| IR Wavelength |
long-life 850 nm IR LED |
| Network |
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ
→ ( will be supported as R/C in July)
Manual(5ea area), WiseStreamⅢ(Based on AI engine) |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Multiple streaming(Up to 5 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
| Application Programming Interface |
ONVIF Profile S/G/T/M
SUNAPI(HTTP API) |
| Security |
| OS / Firmware Protect |
Secure boot, Signed firmware, Firmware encryption |
| User authentication |
Digest Authentication, Prevent brute-force attack |
| Network authentication |
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) |
| Secure Communication |
HTTPS, SRTP, WSS(Websocket secure) |
| Access Control |
Access control based on IP address |
| Data Protect |
Authentication information encryption, ZIP compression encryption |
| Audit |
User Access/System/Event log management |
| Device ID |
Device Certificate(Hanwha Private Root CA) |
| Secure Storage |
SDcard partition encrypt |
| Security Certificate |
Secure by default |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 256GB |
| Memory |
2GB RAM, 1GB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-30°C~+55°C(-22°F ~ +131°F) / 0~95% RH(non-condensing)
* Start up should be done at above -30°C
Humidity control /w Air vent |
| Storage Temperature / Humidity |
-50°C~+60°C(-58°F ~ +140°F) / 0~95% RH |
| Certification |
IP66, IK10 |
| Input Voltage |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
PoE: Max 12.95W, typical 5.3W |
| Mechanical |
| Color / Material |
White / Aluminum
Bubble : Hard-coated dome |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
ø140×110.2mm(ø5.51×4.34″), 875g(1.93 lb) |
| Compatible Conduit hole / Gangbox |
Conduit hole : None
Gangbox : Single, Double, 4″ Octagon |
| Hanging Mount (Dome) |
SBP-140HMW |
| Backbox |
SBV-140BW |
| Certifications & Standards |
| EMC |
FCC 47 CFR 15 Subpart B Class A
ICES-3(A)/NMB-3(A)
CE/UKCA
– EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3
VCCI CISPR 32 Class A
RCM AS/NZS CISPR 32 Class A |
| Safety |
UL 62368-1, CAN/CSA C22.2 NO. 62368-1
IEC/EN 62471 |
| Environment |
IEC/EN 63000
IEC/EN 60529 IP66, IEC/EN 62262 IK10 |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
Wide: 42.7m(140.20ft) / Tele: 186.9m(613.28ft) |
| Observe (63PPM/ 19PPF) |
Wide: 17.2m(56.08ft) / Tele: 75.4m(245.31ft) |
| Recognize (125PPM/ 38PPF) |
Wide: 8.5m(28.04ft) / Tele: 37.4m(122.66ft) |
| Identify (250PPM/ 76PPF) |
Wide: 4.3m(14.02ft) / Tele: 18.7m(61.33ft) |
